Name: HPW Sidewalks 06/03/2022 - 09/01/2022

Display Field: STREETNAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><P><SPAN>Data Transfer Solutions, LLC, (DTS) is headquartered out of Orlando, Florida. DTS is a member of the SNC-Lavalin group. </SPAN></P><P><SPAN>DTS contact information: 482 S. Keller Rd Suite #300, Orlando, FL 32810. Phone: 407-382-5222. </SPAN></P><P><SPAN>www.dtsgis.com. </SPAN></P><P><SPAN>DTS utilizes a fleet of five vans with the following equipment for data collection: </SPAN></P><P><SPAN>Applanix POS LV 420e V5 Navigation System. </SPAN></P><P><SPAN>The POS LV system generates precise, robust positioning and orientation information for mobile data acquisition systems. The system combines all the advantages of GPS with those of inertial technology, to provide continuous and accurate data. By utilizing the POS LV system, data capture can be undertaken quickly and efficiently. </SPAN></P><P><SPAN>IMU: Inertial Measurement Unit generates a true representation of vehicle motion in all three axes, producing continuous, accurate position and orientation information </SPAN></P><P><SPAN>PCS: POS Computer System enables raw GPS data from as few as one satellite to be processed directly into the system, to compute accurate positional information in areas of intermittent, or no GPS reception </SPAN></P><P><SPAN>GPS Receivers: Embedded GPS receivers provide heading aiding to supplement the inertial data </SPAN></P><P><SPAN>GPS Antennas: Two GPS antennas generate raw observables data </SPAN></P><P><SPAN>Sub-meter accuracy: The system is rated to get 0.3 m accuracy in the X,Y position and 0.5 m in the Z position. </SPAN></P><P><SPAN>Distance Measuring Indicator (DMI)</SPAN></P><P><SPAN>BEI 5000 Pulse Incremental Encoder </SPAN></P><P><SPAN>Allows for collection of high-resolution imagery at posted speeds. Distance Measurement Indicator computes wheel rotation information to aid vehicle positioning </SPAN></P><P><SPAN>Cameras </SPAN></P><P><SPAN>Allied Vision Prosilica GX1920C</SPAN></P><P><SPAN>Schneider Compact Lenses </SPAN></P><P><SPAN>Frame rate 15 images per second, 1936x1456 color resolution </SPAN></P><P><SPAN>High-definition cameras with precision lenses allow for accurate asset extraction. </SPAN></P><P><SPAN>Pavement Imaging System </SPAN></P><P><SPAN>INO Laser Road Imaging System (LRIS) </SPAN></P><P><SPAN>Two-line scan cameras and lasers configured to image 4m transverse road sections with 1 mm resolution (4000 pixel) at speeds that can reach 100 km/h </SPAN></P><P><SPAN>Allows fully illuminated pavement image collection even in heavy shadow/canopy areas </SPAN></P><P><SPAN>Surface Road Profiler </SPAN></P><P><SPAN>ICC 5-laser System (Two Selcom SLS6000/375, Three Selcom SLS6375/750) </SPAN></P><P><SPAN>Angle Lasers (SLS6000/375) have a typical accuracy of 0.0002 inches. </SPAN></P><P><SPAN>Point Lasers (SLS6375/750) used to determine rut have a typical accuracy of 0.00037 inches. </SPAN></P><P><SPAN>Used to collect accurate and precise Rutting and Roughness (IRI) values while traveling posted speed limits </SPAN></P><P><SPAN>Acquisition Server/Software </SPAN></P><P><SPAN>Image Acquisition Server running Windows 7 Ultimate with Qcorei7, 8gb RAM, (8) 2Tb disk drives </SPAN></P><P><SPAN>Allows for RAID data capture to prevent loss of data </SPAN></P><P><SPAN>Utilizes Norpix’s Streampix Acquisition software, capable of handling up to 4 cameras triggering simultaneously, with precise timestamps encoded into image EXIF. </SPAN></P><P><SPAN>Streampix allows for on-the-fly image enhancements for dark or bright lighting conditions</SPAN></P><P><SPAN>The total collection consisted of 2,342 miles and spanned from 6/03/2022 to 9/01/2022. Throughout the collection process, the unprocessed data is sent to the DTS headquarters in Orlando where it is converted into processed imagery. Once processed, the DTS team extracts the asset data utilizing DTS' EarthShaper software. </SPAN></P><P><SPAN>Each run of data was reviewed for Sidewalks. During the extraction process, the beginning of the asset is set by two control points, both placed as close to each other as possible to determine the most accurate start point. A series of control points along the asset are set, all extracted the same way utilizing two points in two concurrent images, to create the most accurate line to depict the Sidewalks. </SPAN></P><P><SPAN>Once each run is extracted, the Sidewalks assets are exported. This creates a point/line shapefile and exports a chosen image for each asset from the DTS processed imagery. </SPAN></P><P><SPAN>Once all runs are reviewed and extracted, the shapefiles are then merged together and projected into the geographic coordinate system that most accurately represents the data. </SPAN></P><P><SPAN>Once the Sidewalks are extracted, projected, and merged, the complete data undergoes DTS' quality assurance process. At least ten percent of the total asset features are reviewed by a team member who did not extract the asset. The quality assurance process reviews the location of the asset to make sure it is represented accurately and within three feet or less of the actual location. The attributes populated during the extraction process are also reviewed for accuracy. If the data does not pass the initial quality assurance test, it is revisited to most accurately represent the asset.</SPAN></P><P><SPAN>After the QA process, the data is then imported to a file geodatabase with various domains established to ensure consistency. </SPAN></P><P><SPAN>The extracted data shows that there are 61,425 Sidewalks for a total of 1601 Miles.</SPAN></P></DIV>

Copyright Text: Data Transfer Solutions, 2023

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2996623.937051058
YMin: 1.3762972689775899E7
XMax: 3215984.22864455
YMax: 1.3961377836271897E7
Spatial Reference: 102740  (2278)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 55, 55, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ASSETID ( type: esriFieldTypeInteger, alias: ASSETID )
• IMAGE ( type: esriFieldTypeString, alias: IMAGE, length: 150 )
• STREETNAME ( type: esriFieldTypeString, alias: STREETNAME, length: 250 )
• CONDITION ( type: esriFieldTypeString, alias: CONDITION, length: 30 , Coded Values: [GOOD: GOOD] , [FAIR: FAIR] , [POOR: POOR] )
• WIDTH ( type: esriFieldTypeString, alias: WIDTH, length: 50 )
• STID ( type: esriFieldTypeString, alias: STID, length: 75 )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 250 )
• HYPERLINKS ( type: esriFieldTypeString, alias: HYPERLINKS, length: 150 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
